Description

Output

Number of Outlets
5.0

Receptacle Style
UK BS1363 plug

Input

Nominal Input Voltage
230V

Input frequency
50 Hz +/- 5 Hz

Input Connections
British BS1363A

Cord Length
1.83meters

Maximum Input Current
13.0A

Surge Protection and Filtering

Surge energy rating
918Joules

ts_nm_surge_response
1ns

Peak Current Common Mode
24kAmps

Peak Current Normal Mode
12kAmps

Physical

Maximum Height
55mm , 5.58CM

Maximum Width
385mm , 38.5CM

Maximum Depth
72mm , 7.26CM

Net Weight
0.67KG

Shipping weight
0.79KG

Shipping Height
58mm , 5.8CM

Shipping Width
405mm , 40.5CM

Shipping Depth
130mm , 13.0CM

Color
White

Master Carton Dimensions (Length x Width x Height)
283 x 375 x 428mm

Master Carton Units
12.0

Master Carton Weight
10.25

Units per Pallet
216.0

SCC Codes
1073130431388 2

Environmental

Operating Temperature
0 – 40 °C

Operating Relative Humidity
0 – 90 %

Operating Elevation
0-3000meters

Storage Temperature
-5 – 40 °C

Storage Relative Humidity
0 – 95% no %

Storage Elevation
0-15000meters
